TURA

series overview

series overview

gloss chrome - ZN5
matt chrome - ZN1
stainless steel optic - ZNPVD22
black matt - ZNPVD35

striker door hinge TURA

8962_GW fond

glass-wall 90°

details assembly instructions

art.-nr.	8962
features	opens outwards min. 90° concealed screws oblong hole adjustment adjustable closed position seal profile discontinued in the hinge area
glass thickness	8 / 10 / 12 mm
surface colors	ZN5 = gloss chrome ZN1 = matt chrome ZNPVD22 = stainless steel optic

8961_GW

glass-wall 90°

details assembly instructions

art.-nr.	8961
features	opens outwards min. 90° concealed screws oblong hole adjustment adjustable closed position seal profile discontinued in the hinge area
glass thickness	8 / 10 / 12 mm
surface colors	ZN5 = gloss chrome ZN1 = matt chrome ZNPVD22 = stainless steel optic

8960_GG

glass-glass 180°

details assembly instructions

art.-nr.	8960
features	opens in one direction in- or outwards 180° can also be used for inward 90° concealed screws adjustable closed position seal profile discontinued in the hinge area
glass thickness	8 / 10 / 12 mm
surface colors	ZN5 = gloss chrome ZN1 = matt chrome ZNPVD22 = stainless steel optic

TURA

fantastic solutions for large all-glass installations

angle brackets TURA

8968_GW

glass-wall 90°

art.-nr.	8968
features	oblong hole adjustment concealed screws
glass thickness	8 / 10 / 12 mm
surface colors	ZN5 = gloss chrome ZN1 = matt chrome ZNPVD22 = stainless steel optic

8969_GG

glass-glass 90°

art.-nr.	8969
features	concealed screws
glass thickness	8 / 10 / 12 mm
surface colors	ZN5 = gloss chrome ZN1 = matt chrome ZNPVD22 = stainless steel optic

brochures

TURA
heavy-duty striker door hinge – for oversize showers
